Question

Find the turning point or points on the given curve explain the point is maximum or minimum

y = x (2 x^{2} - 21 x + 72)

Accepted Answer

Given that,

Equation of curve is $y = x (2 x^{2} - 21 x + 72)$

$y = x (2 x^{2} - 21 x + 72) = 2 x^{3} - 21 x^{2} + 72 x$
Any point where gradient of the curve is $0$ ,known as turning point of the curve.
Thus,
Gradient of the curve $(y = 2 x^{3} - 21 x^{2} + 72 x)$

$\frac{d y}{d x} = 6 x^{2} - 42 x + 72$

At turning point,
$\frac{d y}{d x} = 0$
$6 (x^{2} - 7 x + 12) = 0$

$x^{2} - 7 x + 12 = 0$

$(x - 4) (x - 3) = 0$
$x = 4$ and $x = 3$

For $x = 3$ ,
$y = 3 (2 {(3)}^{2} - 21 (3) + 72) = 81$
When, $x = 4$
$y = 4 (2 {(4)}^{2} - 21 (4) + 72) = 80$
Hence,
Turning points on the given curve is $(3, 81)$ and $(4, 80)$
T o check maxima or minima,we need to check second derivative of the curve,
If $\frac{d^{2} y}{d x^{2}} > 0$ then the point must be minimum
And if $\frac{d^{2} y}{d x^{2}} < 0$ then the point must be maximum.
So,
$\frac{d y}{d x} = 6 x^{2} - 42 x + 72 \Rightarrow \frac{d^{2} y}{d^{2} x} = 12 x - 42$
$\frac{d^{2} y}{d^{2} x} = 12 (3) - 42 = - 6 (x = 3) \frac{d^{2} y}{d^{2} x} < 0$
The point $(3, 81)$ is maximum
And
$\frac{d^{2} y}{d^{2} x} = 12 (4) - 42 = 6 (x = 4) \frac{d^{2} y}{d^{2} x} > 0$

The point $(4, 80)$ is minimum.

$x$	$- 2$	$- 1$	$0$	$1$	$2$	$3$	$4$	$5$
$y$	$- 5$		$5$	$7$		$5$		$- 5$

$x$	$- 2$	$- 1$	$0$	$1$	$2$	$3$	$4$	$5$
$y$	$- 5$	$1$	$5$	$7$	$7$	$5$	$1$	$- 5$
