MEDIUM
JEE Advanced
IMPORTANT
Earn 100

If a charged conductor is enclosed by a hollow charged conducting shell (assumed concentric and spherical), and they are connected by a conducting wire, then which of the following statement(s) would be correct?

50% studentsanswered this correctly

Important Questions on Electric Potential

EASY
JEE Advanced
IMPORTANT

Which of the following is true for the figure showing electric lines of force? (E is an electrical field, and V is potential.)

Question Image

EASY
JEE Advanced
IMPORTANT

An uncharged conducting ball B lies inside a charged conductor A as shown in the figure. B is isolated from A.

Question Image

HARD
JEE Advanced
IMPORTANT

For the situation shown in figure, mark the correct statement(s).

Question Image

HARD
JEE Advanced
IMPORTANT

A wire having a uniform linear charge density λ is bent in the form of a ring of radius R. The point A as shown in the figure is in the plane of the ring but not at the center. Two elements of the ring of lengths a1 and a2 subtend very small same angle at a point A. They are at distances r1 and r2 from the point A, respectively r2>r1

Question Image

HARD
JEE Advanced
IMPORTANT
At a distance of 5 cm and 10 cm outward from the surface of a uniformly charged solid sphere, the potentials are 100 V and 75 V, respectively. Then
HARD
JEE Advanced
IMPORTANT
Two infinite, parallel, nonconducting sheets carry equal positive charge density σ. One is placed in the yz plane and the other at distance x=a. Take potential V=0 at x=0. Then
MEDIUM
JEE Advanced
IMPORTANT

A uniform electric field E0 exists in a region at angle 45° with the x-axis. There are two-point A(a, 0) and B(0, b) having potential VA and VB, respectively, then

Question Image

HARD
JEE Advanced
IMPORTANT
A small sphere is charged uniformly and placed at some point Ax0, y0 so that at point B(9 m, 4 m) electric field strength is E=(54i^+72j^) N C-1 and potential is 1800 V. 14πε0=9×109 N m2 C-2, then
