Question

Obtain an expression for the magnetic energy stored in a solenoid in terms of the magnetic field, area and length of the solenoid.

Accepted Answer

A current carrying solenoid has a magnetic field due to current flowing through it. Thus electrical energy is stored as magnetic energy in it. Consider a coil of self-inductance $L$ with number of turns per unit length to be equal to $n$ and area of cross-section $A$ . If $I$ current flows through this, the magnetic field due to this current:

$B = μ_{0} n I$ .....(i)

Self-inductance:

$L = μ_{0} n^{2} A l$ .....(ii)

The self-induced emf in the coil opposes any change in current in the circuit. So work needs to be done against the back emf $(ε)$ in establishing the current. This work done is stored as magnetic potential energy. For the current $I$ at an instant in a circuit, the rate of work done is:

$\frac{d W}{d t} = |ε| I$

$\frac{d W}{d t} = L I \frac{d I}{d t}$

The total amount of work done in establishing the current $I$ is:

$W = \int d W = \int_{0}^{I} L I d I$

Thus, the energy stored in the coil:

$W = \frac{1}{2} L I^{2}$ .....(iii)

On putting the value from (i) and (ii) in (iii), we get:

$W = \frac{1}{2} μ_{0} n^{2} A l I^{2}$

$= \frac{1}{2} \frac{B^{2} A l}{μ_{0}}$ ......(iv)

(iv) is the required relation.
