Question

When the three blocks in are released from rest, they accelerate with a magnitude of $0.500 m / s^{2}$ . Block $1$ has mass $M$ , block $2$ has $2 M$ , and block $3$ has $2 M$ . What is the coefficient of kinetic friction between block $2$ and the table?

Accepted Answer

Given,
Mass of block-1, block-2 and block-3 are $M, 2 M$ and $3 M$ respectively.
Acceleration of the system, $M$ .

Let
$T_{1}$ and $T_{2}$ are tension forces on two different string as shown in the above figure.
$N$ and $f_{k}$ are normal force and kinetic friction acting on block 2 as shown in the above figure.
Acceleration due to gravity, $g = 10 {ms}^{- 2}$

Concept and Formula:
1.Newton's second law of motion:
$\sum_{} F = m a$

2. Kinetic friction:
$f_{k} = μ_{k} N$ , Where $μ_{k}$ is the co-efficient of kinetic friction.

As the block-(2) is not moving along vertical direction.
so, $N = 2 M g$ .

Putting the value of $N$ in kinetic friction $f_{k}$
$\Rightarrow f_{k} = μ_{k} \times 2 M g$

Using Newton's second law of motion on block 2 along horizontal direction.
$T_{1} - T_{2} - f_{k} = 2 M a \dots \dots \dots (1)$

Using Newton's second law of motion on block 3 along downward direction.
$3 M g - T_{1} = 3 M a \dots \dots \dots (2)$

Using Newton's second law of motion on block 1 along upward direction.
$T_{2} - M g = M a \dots \dots \dots (3)$

Add equation-1, equation-2 and equation-3.
$3 M g - f_{k} - M g = 2 M a + 3 M a + M a \Rightarrow 2 M g - μ_{k} 2 M g = 6 M a \Rightarrow μ_{k} 2 M g = 2 M g - 6 M a \Rightarrow μ_{k} g = g - 3 a$

Put the value of $a$ and $g$ in the above equation.
$μ_{k} 10 = 10 - 3 \times 0.5 = 8.5 \Rightarrow μ_{k} = \frac{8.5}{10} = 0.085$

So the value of kinetic friction between the block 2 and table is $0.085$
